About the project

As a result of the agreement made between Liafjord AS and Cemre Shipyard, the construction of LIBAS has started. Su Ship Desing is designing all the advanced detail designs of LIBAS, which the main and detail design designed by Salt Ship Design.


The detail design work to be carried out due to the complexity of the equipment in the fish processing factory and storage system, which is designed as the first LNG propulsion vessel, will be quite comprehensive. Detailed studies are needed for isolation of LNG fuel storage and storage of fish. It is important that the ship, which will have 350m ^ 3 LNG tank and quite large drum areas, will be an environmentally friendly and energy efficient project. Its drum systems will be used to increase the power during hunting and to provide power in emergency situations. In this way, the ship will not need to have an emergency generator. 2830m³ of chilled sea water tanks will be found on the ship and fish will be processed and ready for the port in the factory area.





Features

SHIPYARD: CEMRE SHIPYARD
OWNER: LIAFJORD AD
BASIC DESIGN: SALT SHIP DESIGN
DETAIL DESIGN: SALT SHIP DESIGN
ADVANCED DETAIL DESIGN: SU SHIP DESIGN
CLASS: DNV-GL
FLAG: NORWEGIAN FLAG
LENGTH OVERALL: 86,50m
BREADTH MOULDED: 17,80m /18,80m
DRAUGHT: 7,90m
SPEED: 16,5m
ACCOMMODATION: 16 persons
LNG TANK: 350m³
RSW TANK: 2830m³
